Stationary Concrete Pump JOKI

The JOKI ZW-50 concrete pumps as supplied by Qijiu come in an array of outputs
ranging from 30 cubic meters to 50 cubic meters per hour over distances of
300m. Our trailer-mounted concrete pumps offer the ideal solution for placing
concrete in hard–to-access areas because of their compact size, they can also
be used as an alternative to truck-mounted concrete pumps on larger pours that
require a slower output rate.
Model ZW-50
Concrete output/
m3/hr 30-60
Concrete Pressure/
Mpa 14
Hydtaulic Pump
Output/cc 140
Horizontal Pumping
Distance/m 200-300
Vertical Pumping
Distance/m 60-100
Power 55Kw motor or 84Kw Diesel Engine
Concrete
Cylinders/mm 200*1000
Maxinmun
Aggregate/mm 40
Hydraulic Oil
Capacity/L 240L
Outlet Size/mm 125(100)
Dimensions/mm 4000*1500*1550
Weight/Kg 2600

Minimum Order: 1 sets
