Superda Machine Fire Hose Reel Cabinet Production Machine

Automatic stainless steel enclosure & Mild steel sheet enclosure fire
extinguisher box production line manufacturer.

1, Fire extinguisher box production line technical parameters


No. ITEM PARAMETER REMARK
1 MATERIAL Type MS Steel
T.(mm) 0.9-1.2mm
Yield Strength (Mpa) Q235
2 Forming product Width Customized
3 Forming speed (m/min) 6-13m Including hole
4 Forming main power (KW) 7.5 KW FYR
5 Hydraulic power (KW) 18.5 KW FYR
6 Bending power (KW) 3 KW FYR
7 Voltage AC380V，50Hz，3P


Fire exguisher case production line process

Uncoiler →Straightening→servo feeder→Hydraulic press breach device → Guide
device → roll forming machine → hydraulic punch → Bending enclosure
(optional)→shear device (including knife)→ finished product rack

Fire Hose Reel Cabinet Roll Forming machines (Panel width adjustable)

5.1 Forming Roller：16 stations，and add Rub-roll, To make sure the surface
profile no scratches.

5.2 Side Panel：T.18mm ,A3 steel Heavy duty 。
5.3 Rolling speeding: 6-12 m/min。

5.4 Roller material：GCr15，overall quenching, hardness HRC56-62 ℃.
5.5 Motor power：7.5KW。
5.6 Main Roller ：Dia.75mm，45 #。
5.7 Equipment base: 45 # H type using welded steel plate.
5.8 Transmission: chain drive.
5.9 Security: across the board with emergency stop buttons, easy to handle
emergencies, to ensure that equipment and operator safety. And other gear in
the chain and the staff could easily lead to injury transmission section
covered with protective cover, to ensure the safety of workers.

5.10 Flat collect rack

5.11 Box Bending Machine (including mould)

Minimum Order: 1 sets
