Turbo Electronic Actuator SA1150-42-12V-3787569 for Detroit Diesel S60 14L

SACER SA1150 smart electronic actuator is designed for VGT (Variable Geometry
Turbocharger) systems used in medium-duty and heavy-duty diesel engines. It is
widely applied in turbocharger control to improve engine efficiency, reduce
emissions, and meet current and future exhaust emission standards.

This actuator precisely controls the turbocharger vane position, ensuring real-
time coordination between the engine combustion process and turbocharging
system. It helps optimize air intake, improve fuel economy, and reduce exhaust
pollution in demanding HDV (Heavy Duty Vehicle) applications.

Key features include:

High-precision positioning for VGT turbocharger control
Faster response for improved engine performance and emission control
Supports fuel efficiency optimization and lower emissions
Designed for ISO9001 / IATF16949 compliant manufacturing standards
Wide operating temperature range: -40°C to 125°C
Flexible adjustment angle up to 120° for heavy-duty applications
SACER SA1150 actuator is suitable for a wide range of diesel engine turbocharger
systems where stable performance, durability, and emission compliance are
required.



Specifications

Actuator part No.

3787569

Voltage

12V2
< , br>Software Version

2.28.2

Connector Type

F type

Harness Length

710mm

Coolant

2inM12*1 , .5; 6outM12*1.5

Communication

CAN J1939

Actuator Size

L*W*H=211*87*115.2mm



Notes:

To ensure correct actuator selection and installation:

We strongly recommend that the actuator be installed by a professional using the
necessary scanner or diagnostic equipment for proper pre-alignment with the
turbocharger.
If you are unable to identify your turbocharger actuator manufacturer or part
number, SACER technical staff will assist you with identification.
You may send us a reference photo of your actuator for confirmation before
ordering.


APPLICATION
Turbocharger NO.

2836826 19514480D 23536422 23539062 23539570 2836826 3781169 3786234
378623400 378623400H 378623400HX 3786234H 3792069 3792071 3798597 4033299
4042439 4042439NX 4042439RX 4047597 4047598 4609459 5329513 5352845
5498208 AP80055 E23536422 E23539062 E23539570 R23536422 R23539062
R23539570 170-032-1602 170-032-3627 170-032-3628 1700321602 1700323627
1700323628 3786234HX D92080735R

Application

Detroit Diesel S60 14L(2007-2014)



RELIABILITY & PROVEN QUALITY
1.R&D Innovation Center

Advanced engineering team with 18+ years of turbo system expertise, utilizing
CAD/CAE simulation and rapid prototyping for continuous product innovation

2.Comprehensive Testing Lab

Full-spectrum validation including durability cycles, thermal shock (-40°C to
+150°C), vibration resistance, and EMC compliance testing

3.Quality Management System

IATF 16949:2016 & ISO 9001:2015 certified production with 100% incoming
inspection, in-process monitoring, and final performance verification



END-TO-END ACTUATOR SOLUTIONS
From application evaluation to global delivery, SACER provides reliable actuator
solutions and services for OEM and aftermarket customers worldwide.

1 Product Identification & Model Matching

Based on the product information provided by the customer—such as OE number,
turbocharger model, or product photos—we provide actuator model identification
and matching services to help quickly find the correct replacement.

2 Flexible Customization & Quality Assurance

We provide flexible customization options supported by strict quality control
and validation processes to ensure stable and reliable product performance.

3 Global Delivery & Technical Support

Our global logistics network and responsive technical support ensure efficient
product delivery and long-term cooperation.



WARRANTY & AFTER-SALES SUPPORT
SACER provides warranty coverage and professional after-sales support for our
actuator products. Detailed warranty terms, service conditions, and claim
procedures are available in the official document below.

SACER Product After-Sales Service Terms

Minimum Order: 1 pieces
