Product Description
UVG-250 uv roller varnish is suitable for the whole-sheet roll coating of
paper (applicable substrate: copper paper and white card paper, etc.). With
good adhesion, flexibility, wear resistance and other characteristics, to
provide good luster, wear resistance and other properties. This product is a
base-free light oil, which can simplify the process and save the production
cost.
Safety standards Of UV Roller varnish:
(1)UVG-250 uv roller varnish Meet the EU EN71 PART 3 standards for heavy
metal content.
(2)UVG-250 uv roller varnish Comply with the limit requirements of the
Revised Directive (EU) 2015 / 863 as in Appendix II of the EU RoHS Directive
2011 / 65 / EU.
(3) Pass the phthalate (or ester) safety standards.
(4) Comply with EU Regulation No.1907 / 2006.
Ink technical parametersOf UV Roller varnish:
project surface Viscosity (25℃. Coat 4 cups) adhesion Insulation
levelling property
metric transparency liquid 26 ± 2 seconds good good good
project alcohol resistance Gloss / 60° gloss Light solid energy
Curing speed UV absorption peak
metric Level 4 85 ± 3 degrees 50~80mj/cm2 ≥40M /min 365nm
Recommended Instructions of UV Roller varnish:
1. Stir or shake well before use to prevent stratification of light oil during
placement.
2. The viscosity of UVG-250 uv roller varnish has been adjusted to the use
viscosity. Generally, special diluent is not required.
3. When used, the coating thickness is recommended to be 10~12um, and the
coating amount of 10g / ㎡ UV photofixation energy is set to 50~80mj / cm2The
transfer speed is set to about 40M / min to ensure sufficient curing, otherwise
the surface return adhesion and paint loss during the placement process will
occur.
4. It is recommended to choose more than 2 medium and high pump lamps, line
power 100W / ㎝, single lamp power 5k w / branch, lamp pipe is 12~15 ㎝ away
from the substrate, lamp service life of 800 hours, replaced in time after
aging, to ensure full curing.
