Volkswagen Jetta ABS system teaching board
I. Product Introduction
ABS brake system teaching board is made of ABS brake system, which fully
demonstrates the composition structure and working process of ABS brake system.
It is suitable for teaching ABS brake system theory and maintenance training.
II. Functional features
1. The real ABS brake system can be run, fully demonstrate the composition of
the ABS brake system structure and work process.
Operation control all kinds of switches, can demonstrate the moving ABS brake
electronic control system (solenoid valve conditions, etc.) work process.
2. The panel of the teaching board is made of high-grade aluminum composite
board that is resistant to trauma, pollution, fire and moisture, and the
surface is treated by special process of spraying primer; the panel is printed
with colorful circuit diagrams and working principle schematics that never
fade; the students can visually compare the circuit diagrams and physical
objects to recognize and analyze the working principle of the electric control
system of the moving transmission.
3. The teaching board panel is installed with detection terminals, which can
directly detect the electrical signals of ABS brake system circuit components,
such as resistance, voltage, current, frequency signals, etc. on the panel.
4. The equipment is installed with a diagnostic socket, which can be connected
to a special or general-purpose automotive decoder to read fault codes, clear
fault codes, read data streams and other self-diagnostic functions for the ABS
5. The equipment panel part adopts 1.5mm cold plate stamping and forming
structure, beautiful appearance; the bottom frame part adopts steel structure
welding, the surface is treated with plastic spraying process, with self-
locking castor device, the base of the teaching board is equipped with about
40cm desktop, convenient to place information, testing instruments, etc.
6. The equipment works with ordinary 220V AC power supply, which is converted
into 12V DC power supply by internal circuit voltage conversion and
rectification, without battery, reducing the trouble of charging, 12V DC power
supply has anti-short circuit function.
Overall dimension: 1240×600×1700mm (L×W×H)
External power supply: AC 220V±10% 50Hz
Working voltage: DC 12V
Working temperature: -40℃～+50℃
Steel tube: 40*40*3mm
Cabinet: 1.5mm cold plate stamping and forming, maintenance door set at the
Mobile casters: 100*60mm
Minimum Order: 1 sets
