ZP64CW 32-head Servo Fully-digital Vial-making Machine

ZP64CW 32-head Servo Fully-digital Vial-making Machine

ZP64CW is totally controlled by PLC and servo motor. The functions are
realized by digital-control touch screen operation. Besides, the digital-
control gas volume ratio and the digital working-station positioning assure of
convenient operation and high precision and high stability. The capacity is
more than that of 2 sets of 16-head vial machines, and just need one set of
tube loader, and cover a small area.

Technical Parameter

Item PCS Unit Parameter
Number of Station
Station 32 stations in Part-A
22 stations in Part-B
Efficiency
PCS/hour 2500-3500
Size of Vial Outer Diameter
mm Ф12-24
Height
25-80
Inner Diameter of Neck
Ф6-20
Frequency Conversion Motor Type

YR100L-6
Power
KW 1.5
Voltage
V 380
Rotation
r/min 940
Servo Motor for Part-A Power 1 KW 2
Voltage V 220
Servo Motor for Part-B Power 1 KW 1
Voltage V 220
Servo Motor for Tonger Power 5 KW 0.4
Servo Motor for Vial Height Power 1 KW 0.4
Servo Motor for Opening Chuck in Part-A Power 1 KW 0.4
Servo Motor for Opening & Closing Chuck in Part-B Power 1 KW
0.4
Servo Motor for Chuck Rise and Fall in Part-B Power 1 KW 0.4
Servo Motor for Opening & Dropping in Part-B Power 1 KW 0.4
Machine Size mm 2200x1250x1800
Assemble Size mm 2200x1250
Weight KG 4700
Pressure(only for reference) Gas/Natural Gas Mpa 0.012/0.012
Liquid Gas/Oxygen 0.05/0.014
Air 0.02
Consumption(only for reference) Gas/Natural Gas m³/hour 5-6/2-2.5
Liquid Gas KG/hour 1.4-2
Oxygon/Air m³/hour 11/12-20
