PTM-120T Chip Module Initialization and Testing Machine

PTM-120B can be integrated short-circuit punching,open and short test,chip
initialization & pre-personalization as well as reject chip punching and
marking.The brand-new design enables operators to switch chips production
between 6PIN and 8PIN within 60 seconds. Modular design can meet your different
production requirements and maximize decreasing your investment cost.

PTM-120B can be applied to contact/contactless and dual interface chip
initialization,and also can be customized according to the demands for various
chip production.

Specifications of PTM-120T Chip Module Initialization and Testing Machine
PARAMETER
Capacity 53000UPH
Dimension 4750mm×840mm×1960mm(including broken reinforcement units);
3800mm×840mm×1960mm(excluding broken reinforcement units)
Weight 800kg (including broken reinforcement units);
650kg (excluding broken reinforcement units)
Power Supply 220V (-5%~+10%) 50Hz 4KW (including broken reinforcement unit);
220V (-5%~+10%) 50Hz 2KW (excluding broken reinforcement units)
Air Supply No air source required
Noise <50dB
Operation Temperature Room temperature: 23℃±3℃
Operation Humidity 50±10%
Maximum Throughput 60,000 UPH (including broken reinforcement units);
120,000UPH (6PIN, excluding broken reinforcement unit)
Short-circuit Punching Throughput Maximum production capacity 60000 UPH
(14 pieces per round)
Chip Module Specification M2, M3
Communication Interface Ethernet

Functions of PTM-120T Chip Module Initialization and Testing Machine
PARAMETER

Discharge Unit
The position adjustment of the active and driven material trays is convenient
and can adapt to different incoming directions; Compatible with 12.6MM and 38MM
shaft diameter material trays.

Main Writing/testing Unit
Compatible with 6PIN and 8PN chip production; Supports up to 120 contact test
heads and 12 non-contact test heads simultaneously for electrical performance
testing and data writing of contact, non-contact, or dual interface modules;
Alternatively, 60 contact test heads and 60 non-contact test heads can be
configured according to customer requirements. This unit can work
independently.

Supplementary Writing/testing Unit
Configure 2 sets of contact test heads or 3 sets of non-contact test heads to
automatically write/test failed chips, minimizing waste.

Gun Waste Unit
The identification of punch holes for chips that have failed to write or test
can be flexibly set through software without the need for manual adjustment,
greatly improving the accuracy and production efficiency of punch holes; This
unit can work independently.

Material Receiving Unit
Roll up the written and tested strips and wrap them with protective tape; This
unit can work independently.

Broken Reinforcement Unit (Optional)
Capable of cutting the connecting ribs of chip strips; By changing the mold, it
is easy to cut different specifications of chip strips; This unit can work
independently.

Advantage of PTM-120T Chip Module Initialization and Testing Machine
WHY

Unique patented technology
1. The equipment is compatible with 6pin and 8pin module strip production.

2. Unique patented technology for fast switching of chip types: It can quickly
switch between 6pin and 8pin production tasks within 60s without removing and
inserting cables.

120 Heads ensure high throughput
Max.throughput 100,000cph for 6PIN chip;

Max.throughput 77,000cph for 8PIN chip.

High-performance reader
The top Chinese industrial-class reader developed by Piotec with open/short
test function is stable and high cost-effective.

Visual inspection
Independent side hole visual detection module can carry out high-speed and
high-precision real-time detection of side holes and waste holes to ensure the
accuracy and precision of side hole detection.

The flexible testing scheme is suitable for different IC module applications.

Reject chip punching module
Independent punching mechanism can accurately set the punching position of
double row chip through parameters (XY direction can be used), without
adjusting the position of mechanical structure, high precision and good
punching consistency.

Unrestricted workplace
Free of production site due to electric driving design without external air
supply.

Electrical performance parameters testing items
Open-short test for pins (positive and negative current is adjustable).

Leakage current test supported.

Static current test supported.

FVMI and FIMV (V=f(I), I=f(V)) supported.

Pin voltage value of Vih and Vil is Adjustable.

We can offer types of credit card making machine for sale , if you have needs
to buy credit card creator machine, credit card maker machine, credit card
manufacturing machine, please contact us.

If you want to know more about credit card manufacturing process, please visit
our website.

As a smart card supplier, we will do our best to meet all the needs of
customers.

Minimum Order: 1 sets
