17AM snap action thermal switch thermostat

17AM series snap action thermostat. Self-sustaining function can be realized by
parallel PTC or heating wire. With the advantages of quick tripping, anti-arc, high
temperature control accuracy, temperature sensitive, long life, at the same time,
have the same direction/ opposite direction two different terminals. Widely used in
water pump, vacuum cleaner, high power motor, electric heating seat, electric
blanket, automobile heating pad, medical heating pad and otherelectric heating
fields.

Rated Current&Voltage AC250V/9A、 DC24V/9A

Operating Temperature 55°C~160°C

Size:17AM-A 23mm ( L ) *10.5mm ( W ) *4.8mm ( H )
17AM-A+PTC 23mm ( L ) *10.5mm ( W ) *6.5mm ( H )
17AM-B 25mm ( L ) *10.5mm ( W ) *4.8mm ( H )

Lead Wire UL3135 AWG18#、 UL3321 AWG18#、UL3321 AWG20#

Minimum Order: 100 pieces
