2BV Single stage liquid ring vacuum pump with flange or threaded suction an

Liquid ring vacuum pump with flange or threaded end for suction and exhaust

2BV series liquid ring vacuum pump is suitable for suction gas and vapour ,and the
suction pressure can reach 33mbar (97% vacuum degree ).When the liquid ring vacuum
pump works under the condition that the suction pressure is near the limited vacuum
(saturated pressure of the operating liquid )for a long time ,it should couple with
the cavitation protection pipe in order to protect the pump .When it is used as a
compressor ,the maximum pressure is 0.26mpa.As a new generation of energy-saving
pump,2BV series liquid ring vacuum pump will replace the SK and 2SK series liquid
ring vacuum pumps and W,WY,WL series reciprocating vacuum pumps completely with
their superior performance and advantages .

2BV6 series liquid ring vacuum pumps and compressors are mainly used for pumping
the explosive gas or working in the flammable and explosive environment. The
technical parameter of each type is the same as the corresponding type of the
2BV2and 2BV5 series pumps.

Advantages:

1. The direct-coupled design is easy installation, and it can save space.

2. The pump has the cavitation protection port opens (or connects with the
separator) in the case of ensure maximum suction effect to eliminate the noise of
cavitation and protect the pump

3. 2BV whole series are all use the bronze impeller with high strength and raise
its corrosion resistance and durability .If the liquid flows parts adopt stainless
steel ,the pump can work in the more hard condition .



Application:

Pulp & paper industry: black liquid evaporation, vacuum dehydrator, degassing
system of raw materials and white water, suction tank, couch roll, absorption-shift
roll and transmission roll, Anti-wind box.



Chemical industry: methane gas recovery, petroleum recycles, gas collection,
exhaust compression, vapor collection, filtration and decertation, polyester
Production, PVC Production.

Power plant: condenser exhausting, water box priming, flue gas desulfurization, fly
ash conveying, geothermal gas removal, Vacuum Pressure impregnation for
transformers.

Sugar industry: Sewage filtering, CO2 production etc

Minimum Order: 1 sets
