AAK Hydraulic Cartridge Directional Control Valve Spool 1μm accuracy

Ctenah is from Russia. In early July of this year, he left a message on AAK
hydraulic valve website: We mainly purchase hydraulic cartridge flow control
valves from India and Europe. Due to the prices in Europe and the instability
in India, we would like to try to find a long-term cooperative supplier of
hydraulic cartridge valves from China. Based on my over 20 years of experience
and multiple visits to AAK hydraulic valve websites, I believe AAK is a good
option. At present, we have a customized model that has been tested 3 times in
the Indian factory, but the stability of hydraulic cartridge flow control valve
accuracy is still not solved. If you are willing to develop the Russian market,
we will start working together with this hydraulic cartridge flow control
valve.

I really appreciate Ctenah's frankness and checked their company online. Their
product line is very compatible with AAK, and the quality of hydraulic
cartridge valves is also very particular. He seems to be very cheerful, which
is the target customer base of AAK hydraulic valves.

According to the hydraulic cartridge flow control valve samples sent by Ctenah
from the original Indian factory, and his original design drawings, the
accuracy requirements are high, especially the 1μm valve spool is difficult,
without unique skills, it is hard to maintain the stability of precision. For
each batch of hydraulic cartridge flow control valves, there will be always a
part that will leak. I think this is the reason why Ctenah was not satisfied
with the 3 times of samples sent by the Indian factory. I told Ctenah that the
key to the accuracy of this valve spool is polishing, which not only requires
high-precision grinding machines, but also segmented cutting techniques.

After 40 days, AAK sent out 12 samples of hydraulic cartridge flow control
valves. Last week, Ctenah's email us, stating that AAK sample accuracy meets
the requirements, and there are 17 models of hydraulic cartridge hydraulic
valves attached for AAK to quote. They will visit AAK factory by the end of
October. I expect AAK to become his most stable hydraulic cartridge valve
supplier in Ningbo China. He used 20 years of experience as a guarantee, and I
gave back his choice with 1 successful sample. Sometimes, business is often
simple.

The precision machining of the hydraulic cartridge flow control valve spool is
carried out by AAK using Japan's Tsugami cylindrical grinding CNC lathe. This
equipment was previously mostly used in the military industry, with the
advantages of centralized control rods, the characteristic of no deviation in
spindle rotation, and the stability and seismic resistance of the plastic guide
rail. It is qualified to challenge 1μm accuracy. The equipment engineer first
adjusts the cutting stroke of the equipment based on the hydraulic cartridge
flow control valve spool, and then cuts the blank parts in sections according
to the contour of the spool. Using the entry method, the blank parts are finely
ground in sections, leaving a capacity of 0.03. This is crucial, as leaving
more or less will have an impact. When cutting by segment, there is 1 more
detail that is also crucial: adjacent to two segments, set a 5mm overlap
interval. Most hydraulic cartridge valve manufacturers do not delve deeply into
these 2 details, which also leaves a potential problem for unstable accuracy.
Finally, the vertical method is used for precision polishing, and the speed is
controlled at 70% of the general speed. Although the efficiency is low, it is
beneficial for the stability of accuracy.

AAK hydraulic cartridge flow control valve, 2 details, 2 methods, challenging
1μm accuracy. You can also give it a try!
