Cylindrical lithium battery production line

Cylindrical lithium battery production line
Product Description
Device Introduction: The process process from the battery warming tunnel
furnace completes from the scroll around the Lithium Battery Production Line to
the preheating baking section. The battery cells are heated on the conveying
line of the constant temperature stove, and the heating pipe is used to
generate heat in the heating pipe. The fan is used to stir. Essence
Equipment advantage:
1. Simple design and energy saving;
2. Covering the area is small;
3. Compatible with replacement.
Hot Press
Device profile: Thermal compressor is used to plasticine the battery after the
winding, mainly including heat pressure and Hi-POT testing; the device can make
the heat pressure duration, thermal pressure temperature, thermal pressure
pressure, Hi-POT test duration, testing test duration, testing As a result, the
information such as the scanning barcode corresponds to one -to -one code, and
the corresponding information is stored to the industrial PC and uploaded to
the MES system.
Equipment advantage:
1. The battery connection process does not hurt the battery cell;
2. The hot pressure plate is pressed naked batteries, which is evenly heated;
3. Thermal pressure temperature detection;
4. Hi-POT test.
