DBY electric power diaphragm pump

DBY electric power double diaphragm pump electric diaphragm pump is driven by an
electric motor through a reducer, and the pump is widely used to transport various
corrosive liquids, liquids with particles, high viscosity, volatile, flammable, and
highly toxic liquids. Parameters: Flow rate: 0-20m3/h; Lift: 30m; Power: 0.37-4kw;
Speed: 1450r/min; Caliber: 10-100mm; Temperature: -15-+150 ℃; Self suction height:
5-7m Diaphragm pump material: cast iron, aluminum alloy, stainless steel, PTFE
lining F46, rubber lining. Diaphragm material: acrylonitrile butadiene rubber,
Neoprene, fluororubber, polytetrafluoroethylene, polytetrafluoroethylene F46.
Sealing ball material: nitrile rubber, Neoprene, polytetrafluoroethylene, stainless
steel, ceramic. Material of sealing ball seat: NBR, Neoprene, fluororubber,
polytetrafluoroethylene Motors can be divided into ordinary motors, explosion-proof
motors, reduction motors, and electromagnetic speed regulating motors

Minimum Order: 1 sets
