FBI & STQC Certified Fingerprint Scanner

SM-91M Type C Fingerprint Scanner Overview:
Miaxis® SM-91M(TMF20) device is a FBI PIV&Mobile ID FAP20 certified single
optical Fingerprint Scanner.
It's a compact & portable fingerprint collection device for easy integration
with new or existing applications.
Powered by USB 2.0/3.0 and supports Windows, Linux and Android operating
systems.
Ideal for biometric authentication and personal identity verification programs.
TMF20 is marketing model in india, designed for India UIDAI Aadhaar Biometric
ID program, STQC, FBI-PIV, WHQL certified.

SM-91M Fingerprint Scanner Type C Feature:

500dpi resolution

Lightweight and durable design for portable use

High-quality fingerprint image FBI-PIV & Mobile ID FAP20 certified

MIAXIS, ISO 19794-2&ANSI 378 Template Options

Standard USB interface, plug&play device,1.5m cable length.

IP54 rated dust and water protection design

Live finger detection technology

SM-91M Type C Fingerprint Scanner Specification:
Specification Detail
Sensor type Optical
Resolution 500dpi
Active platen area 15.24mm x 20.32mm
FAP (fingerprint acquisition profile) FAP20
Maximum Acquisition time (Placement to Template) <3s
Grey scale 8 bit (256 levels )
Live finger detection Yes
Platen Ingress Protection IP54 (platern surface)
ESD immunity +/-8kV contact discharge;+/-15kV air discharge
Supply voltage DC 5V±5%
Communication interface USB2.0
Operating Temperature -10°C to +45°C
Storage Temperature -20°C to +50°C
Operating humidity 20%RH～90%RH
Product size 60*40*21.9mm (L*W*H)
Weight 80g
Operating system environment Windows XP/Windows 7/ Windows 10 Android
4.0/5.0/6.0

If you want to know more about fingerprint machine price, please visit our
website.

As a biometric device company, we will do our best to meet all the needs of
customers.

Minimum Order: 1 pieces
