Flake Ice Machine

A Flake Ice Machine is one of the most widely used industrial ice-making
systems for rapid cooling, temperature control, and product preservation. Known
for its thin, dry, irregular ice flakes and exceptional heat exchange
efficiency, flake ice is essential in industries such as seafood processing,
food manufacturing, concrete cooling, chemical processing, and refrigeration.
Compared with other ice types, flake ice provides faster cooling, larger
contact surfaces, and gentler handling for sensitive products. For businesses
seeking reliable and energy-efficient cooling solutions, investing in the right
flake ice machine can significantly improve productivity and product quality.
Model Parameters FD05 FD10 FD30 FD50 FD100 FD150 FD200
FD300 FD400 FD500
Daily output (T/24h) 0.5 1 3 5 10 15 20
30 40 50
Compressor Power(KW) 1.15 2.006 9.8 15 33 46 75
82 157 180
Fan Power for Cooling Tower 0.18kw 0.45KW 1.2KW 2.25KW 3.7KW 1.5KW
1.5KW 2.25KW 3.75KW 3.75KW
Cooling Pump Power / / / 0.75KW 1.5KW 5.5KW 7.5KW
7.5KW 11KW 11KW

Click to Enlarge
