High-Quality C70600 Copper-Nickel Marine Pipes - Reliable Performance

In marine environments such as shipbuilding, offshore platforms, and seawater
transmission systems, piping materials are continuously exposed to severe
conditions including seawater corrosion, erosion, marine biofouling, and cyclic
temperature changes. Ordinary carbon steel and stainless steel pipes can be
prone to rusting, perforation, short service life, and high maintenance costs.
C70600 copper-nickel marine piping, also known as 90/10 copper-nickel alloy
piping, offers outstanding seawater-corrosion resistance and stable mechanical
properties. It is therefore a mainstream choice for marine piping systems and
is widely used in ship seawater cooling systems, ballast-water pipelines, fire-
fighting lines, and offshore-platform process pipelines.
Product Overview
This product is a high-quality C70600 copper-nickel alloy seamless pipe,
corresponding to Chinese grade BFe10-1-1 (B10 iron cupronickel). It can be
manufactured in accordance with international standards such as ASTM B111, ASTM
B466, and ASTM B122. Certifications from major classification societies,
including CCS, ABS, DNV, LR, BV, and others, can be provided upon customer
request.
The alloy uses copper as the base metal and contains 9%-11% nickel, 1.0%-1.5%
iron, and an appropriate amount of manganese, forming a stable single-phase
solid-solution microstructure. Nickel significantly improves corrosion
resistance and strength; iron effectively enhances resistance to erosion
corrosion caused by flowing seawater; and manganese further improves processing
performance and corrosion resistance.

Key Advantages of 90/10 Copper-Nickel Pipe
1. Excellent Seawater Corrosion Resistance
Copper-nickel alloy quickly forms a dense and stable protective oxide film when
exposed to seawater. This film effectively resists pitting corrosion, crevice
corrosion, and erosion corrosion caused by high-velocity seawater. The material
performs reliably in both stagnant and flowing seawater, greatly reducing the
risk of leakage.
It also naturally inhibits the attachment of marine organisms such as
barnacles, shellfish, and algae, reducing pipeline blockage caused by
biofouling and lowering cleaning and maintenance frequency.
2. Stable Mechanical Properties
C70600 copper-nickel pipe has good tensile strength and toughness. It is not
prone to brittle fracture under low-temperature conditions and performs well
under vibration, impact, and cyclic loads encountered during vessel operation.
The material also offers excellent fabrication performance and supports
bending, welding, and expanding, making on-site installation convenient.
3. Good Thermal Conductivity
Its good thermal conductivity makes it suitable for ship seawater cooling
systems. Heat-transfer efficiency remains stable during long-term operation,
without the performance degradation caused by rust or severe corrosion, helping
ensure the reliable operation of marine power systems.
4. Fatigue Resistance and Long Service Life
Compared with carbon steel piping, C70600 copper-nickel pipe provides a longer
service life in marine environments. It reduces shutdown time, inspection
requirements, replacement frequency, and overall maintenance costs, making it
especially suitable for long-term offshore operations.
5. Natural Resistance to Marine Biofouling
In natural seawater, C70600 continuously releases trace amounts of copper ions,
effectively inhibiting the growth and attachment of barnacles, shellfish, and
other marine organisms. This can significantly reduce the need for chemical
anti-fouling treatment and pipeline cleaning.
6. Excellent Weldability and Fabrication Performance
C70600 can be reliably joined using TIG or MIG welding processes. ERCuNi
welding wire with argon shielding gas is recommended. The material is also
suitable for cold drawing, rolling, stamping, and other forming processes.

Minimum Order: 1 tons
