High Temperature Accelerated Aging Chamber Manufacturer for Battery Cell an

DGBELL’s Temperature Aging Test Chamber is widely used for the aging test for
electronic products, solar panel, plastic products, especially for battery
temperature aging test.


Main Technical Parameter


Model
BTG-720
BTG-1000< , br>Test Space mm
W1000*H1200*D600
W1000*H1000*D1000
Ext , ernal Dimension mm
W1200*H1815*D920
W1400*H1850*D1270
Tem , perature Range
RT+10℃ ~ +150℃(Fully controllable, adjustable control accuracy ±0.1℃)
Temperature Fluctuation
±0.3℃
Temperature Uniformity
≤±2℃ (at no load, constant state)
Observation Window
W300*H300 MM, explosion-proof glass and affixed with explosion-proof film
Cooling Method
Air-cooled
Control Mode
Touch screen programmable control PLC, with USB interface, with RS485 interface
can be connected to computer control, special network control software,
convenient remote monitoring, data acquisition
Test Space material
SUS304# mirror stainless steel, 1.0MM thick, sprayed Teflon insulation
External Dimension material
Galvanized plate, powder coating, high temperature plasticization, 1.2MM thick
Safety Protection
Automatic explosion-proof pressure relief device, explosion-proof chain,
tricolor light device alarm, remote monitoring, smoke exhaust device, fire
extinguishing device, etc.
Lead Hole
Φ100mm left and right each open one with soft silicone plug and stainless
steel cover
Expansion Function
Open communication protocol and charging and discharging machine supporting use
