Instrument PCBA Board

HX Electronic Ltd produces PCBassembly since 2010, more than 10 years
experience, HX Technology is advancing rapidly, Obtained a large number of
European and American countries customers of all ages, We can do We can
assemble any SMD and THT regular components onto any medical PCB to meet any of
your requirements and configurations. If needed, we can also provide assistance
with circuit board layout, panel optimization, and production design.

When manufacturing plenty of PCB boards, it is impossible to solder parts by
hand. You will need PCB instruments to complete this step, to make a bare
board, and assemble all parts onto the printed circuit board. There are many
issues to consider at each stage of the assembly process, to provide a perfect
functional printed circuit board. As a professional PCB board manufacturer, HX
Technology provides high-quality PCB instruments for customers.

Introduction to PCBInstrument
The basic instruments required for PCB assembly includes:

Solder Paste Printing machine

Solder Paste Inspection (SPI) machine

Glue Dispensing machine

Pick-and-Place machine

Reflow Soldering machine

Wave Soldering machine (for through-hole components)

Automatic Optical Inspection (AOI) machine

In-Circuit Test (ICT) Fixture

Functional Validation Test (FVT) Fixture

Minimum Order: 1 gallons
