Jerry-C Thermal Monocular Helmet Mount

Jerry C Clip-on Thermal Imager has removable wide-angle HD lens and multiple
display modes to deliver better environment sensing performance.

Resolution: 640×512

Pixel size: 12μm

Features of Jerry-C Thermal Monocular Helmet Mount
Ceramic packaged HD thermal imaging.

Latest 12μm HD infrared module, stronger, lighter, and smaller.

Ultra-low load, quick installation, and uninstallation.

Quick removal interface allows plug-and-play infrared fusion function.

Fusion display and threat recognition.

Multiple application modes facilitate hot target searching and displaying,
helping users to grasp the initiative.

Video of Jerry-C Thermal Monocular Helmet Mount
Applications of Jerry-C Thermal Monocular Helmet Mount

Jerry-C Thermal Monocular Helmet Mount Applications

Specifications of Jerry-C Thermal Monocular Helmet Mount
Detector Type Uncooled VOx infrared detector
Detector Resolution 640×512
Pixel Size 12μm
FOV 30.5
View Ratio (40° night vision device) 0.765
Display Mode Manual/Automatic
Image Mode White-hot/Highlight/Outline
Power Supply 17335,18650
Weight 78g/110g
Interface External power supply/Analog video (PAL)/RS232
Operating Temperature -40°C~+60°C
Ingress Protection Rating IP67

As a reliable ir camera supplier, we can offer kinds of related products for
sale, if you have needs, please contact us.

Minimum Order: 5 pieces
