JM Series (AGM Deep Cycle Battery)

JM series battery is specially designed for UPS system, emergency power and
security system applications. Using thick plate and high corrosion resistance
grid alloy, matching with high-impact AGM separator, the battery maintains high
consistency for better performance and reliable standby service life.
Specification of JM Series (AGM Deep Cycle Battery)

Model Nominal
Voltage Capcity
(C10) Dimension Weight Terminal
Length Width Height Total Height Kg Lbs
V Ah mm inch mm inch mm inch mm
inch
JM12-33A 12 33 195 7.68 130 5.12 167 6.57
167 6.57 10.0 22.05 M6
JM12-33B 12 33 197 7.76 165 6.50 170 6.69
170 6.69 11.0 24.25 M6
JM12-38 12 38 197 7.76 165 6.50 170 6.69 170
6.69 12.5 27.56 Cable/M6
JM12-50 12 50 229 9.02 138 5.43 212 8.35 215
8.46 15.5 34.17 M6
JM12-55 12 55 229 9.02 138 5.43 212 8.35 215
8.46 16.5 36.38 M6
JM12-65 12 65 350 13.78 166 6.54 175 6.89 175
6.89 19.5 42.99 M8
JM12-70 12 70 258 10.16 168 6.61 208 8.19 211
8.31 21.8 48.06 M6
JM12-80 12 80 258 10.16 168 6.61 208 8.19 211
8.31 24.0 52.91 M6
JM12-85 12 80 258 10.16 168 6.61 208 8.19 211
8.31 26.0 57.32 M6
JM12-90 12 90 307 12.09 168 6.61 211 8.31 214
8.43 26.0 57.32 M6
JM12-100A 12 100 330 12.99 171 6.73 216 8.50
219 8.62 29.5 65.04 M8
JM12-100B 12 100 407 16.02 170 6.69 220 8.66
223 8.78 32.5 71.65 M8
JM12-120 12 120 407 16.02 170 6.69 220 8.66
223 8.78 35.0 77.16 M8
JM12-135 12 135 341 13.43 173 6.81 281 11.06
286 11.26 41.5 91.49 M8
JM12-150A 12 150 483 19.02 170 6.69 241 9.49
241 9.49 42.5 93.70 M8
JM12-150B 12 150 483 19.02 170 6.69 241 9.49
241 9.49 45.0 99.21 M8
JM12-200 12 200 522 20.55 240 9.45 219 8.62
222 8.74 57.0 125.66 M8
JM12-250 12 250 520 20.47 268 10.55 220 8.66
223 8.78 68.0 149.91 M8
JM6-225 6 225 243 9.57 188 7.40 275 10.83 275
10.83 31.5 69.45 M8

Characteristic of JM Series (AGM Deep Cycle Battery)
Valve Regulated design, no free liquid electrolyte, Maintenance - free
Designed floating service life: 10 years @ 25˚C
Stable performance and small internal resistance, good high performance for
recycle use
Thickened Sn alloy plate and the grid with corrosion resistance
Wide operating temperature range: -15-35˚C
Self-discharge rate: ≤ 3% / month

Application of JM Series (AGM Deep Cycle Battery)
UPS uninterrupted power supply, EPS equipment, toys, lamps and lanterns,
computers, electric wheelchair, portable device, medical equipment, cable TV,
rolling shutter door, outdoor mobile speakers, electric scooter, electronic
cash register.
