JPC Series (Lead Carbon Battery)

Lead-carbon battery is the combine of lead-carbon dual function negative pole
plate which makes of both dual electric layer capacitance carbon material (C)
and lead (Pb) to achieve the capacitance & battery feature, then the lead-
carbon batteries assembled by lead-carbon negative pole plate and positive pole
plate.

As one of the leading solar energy battery manufacturers/suppliers/companies in
China, KIJO provides quality solar power battery with low price/cost.

Specification of JPC Series (Lead Carbon Battery)

Model Nominal Voltage(V) Capacity
(C10) Dimension Weight Terminal
(Ah) Length Width Height Total Height Kg Lbs
mm inch mm inch mm inch mm
inch
JPC12-38 12 38 1.8VPC 197 7.76 165 6.5 170
6.69 170 6.69 12.5 27.6 M 6
JPC12-65 12 65 1.8VPC 350 13.78 166 6.54 175
6.89 175 6.89 21 46.3 M 6
JPC12-70 12 70 1.8VPC 258 22.36 168 6.61 208
8.19 211 8.31 22.5 49.7 M 6
JPC12-90 12 90 1.8VPC 307 12.09 168 6.61 211
8.31 214 8.43 28.5 62.8 M 6
JPC12-100 12 100 1.8VPC 330 12.99 171 6.73 216
8.5 219 8.62 30.8 67.9 M 8
JPC12-120 12 120 1.8VPC 407 16.02 173 6.81 237
9.33 237 9.33 37.2 82 M 8
JPC12-150 12 150 1.8VPC 484 19.06 170 6.69 241
9.49 241 9.49 47 103.6 M 8
JPC12-200 12 200 1.8VPC 522 20.55 240 9.45 219
8.62 222 8.74 61.5 135.6 M 8
JPC12-250 12 250 1.8VPC 520 20.47 268 10.55 220
8.66 223 8.78 71 135.6 M 8
JPC2-500 12 250 1.8VPC 241 9.49 172 6.77 330
12.99 366 14.41 29.5 65 M 8
JPC2-1000 2 1000 1.8VPC 475 18.7 175 6.89 328
12.91 365 14.37 65.1 143.5 M 8
JPC2-1500 2 1500 1.8VPC 401 15.79 351 13.82 343
13.5 378 14.89 96 212 M 8
JPC2-2000 2 2000 1.8VPC 491 19.33 351 13.82 343
13.5 383 15.08 128 282.2 M 8
JPC2-3000 2 3000 1.8VPC 712 28.03 353 13.82 342
13.43 382 15.03 192 423 M 8

Characteristic of JPC Series (Lead Carbon Battery)
Designed floating service life : 15 years at 25˚C.
Cycle usage : 70% DOD above 1900 cycles.
Self-discharge rate : ≤ 3% / month.
Wide operating temperature range：-35 to 60˚C.

Application of JPC Series (Lead Carbon Battery)
New energy storage like wind/solar generating storage
New energy vehicle like hybrid electric vehicle and electric bicycle
etc.

Founded in 1993, KIJO battery Group is a professional china solar battery
manufacturers and solar energy battery manufacturers, we provide chinese solar
batteries, sun energy battery, batteries for a solar system, Reserve Power
Battery, Motive Power Battery, Lithium Battery, china storage battery, energy
storage battery and etc. Want to know about solar energy battery storage costs?
Please contact us.
