Lab Pharmaceutical Factory Air Quality Particle Counter 100LPM 80W

Portable Air Particle Counter Lab Pharmaceutical Factory



The real-time display of particle data of 0.5, 1.0, 3.0, 5.0 10 and 25μm 6
channels can be switched to display the actual particle number or particle
concentration value (1m3). The dust particle counter has built-in long-life laser
diode, light collection elliptical lens and unique optical system to provide
concentration measurement range.



​Specification of particle counter

Model Y09-5100
Outside Dim 268×192×292(mm3)
Display 7inch Color Screen
Weight 8.4kg
Max.Consumption 80W
Power Source DC16.8V
Size Channels 0.5, 1, 3, 5, 10, 25μm
Flow Rate 100L/min
Sample Time 6~999999s(Selectable)
Zero Count ≤10min
Hold Time 0-9999s
Delay Time 5-999s
Printer Built-in Thermal Printer
Data Storage 20000 Samples/300Samples of UCL(With PC Software)
Maximum Rated Particle Concentration 35000 particles/L
Operating Time More than 5.5 hours
Environmental Temperature:10~35℃; Humidity:20%~75%RH; Atmosphere
Pressure:86~106Kpa
Material SUS316L Stainless Steel
Class ISO14644-1:2015/GMP:2015


Application of air particle counter

Clean room cleanliness detection
Pharmacy or electronic industry routin inspection
High concentration aerosol measurement
Airborne particle measurement
Filter leakage test
