Liquid Detergent Pesticide Filling Machine 24 Bpm Bottle Filling Machine So

PRODUCT DESCRIPTION
16 Filling Heads 50ml-1000ml Following Type Pesticide Filling Machine 7.5KW





Following Type Pesticide Filling Machine Highlights





1 Automation Intelligent automatic packaging line 2 operators
2 Adjustment Handle structure
Easy to adjust

Name cards All parts has name cards, easy to recognize
3 Capping process Torque control Good sealing performance
4 Safety production Safety operation Satety protection,
electrical protection


Following Type Pesticide Filling Machine Parameters



1 Capacity ≤9000 Bottles/hour for 100ml size bottle
2 Bottle size Φ30－100mm height 80-250mm
3 Cap size Φ20－80mm height 20-40mm
4 Accuracy ≤±1g(200ml)；≤2g(200-1000ml)*water as example
5 Feeding port height 2380mm
6 Feeding port diameter Dn90
7 Nozzle diameter Φ18mm
8 Minimum bottle opening ≥Φ22mm
9 Air pressure 0.6-0.8MPa
10 Power ～380V 50Hz/7.5KW
11 Machine size 5310×1790×2437mm(L×W×H)
12 Machine weight Around 4000kg




Following Type Pesticide Filling Machine Configurations



S/N Name Brand
1 PLC Schneider
2 Touch screen Schneider
3 Frequency converter Schneider
4 Servo system Schneider
5 Counting sensor Sick
6 Proximity sensor Leuze
7 Switch power supply Schneider
8 Pressure switch SMC
9 Cylinder FTEC
10 Solenoid valve FTEC
11 Buttons Schneider
12 Alarm light Schneider
13 Breaker Schneider




































Following Type Pesticide Filling Machine Application



GX-16-8AH filling and capping 2 in 1 machine can perfectly finish the
filling and capping process in different kinds of area, such as pesticide,
fine chemical, daily chemical, fertilizer, oil and other industries.

Liquid Detergent Pesticide Filling Machine 24 Bpm Bottle Filling Machine
Solvent Filling Machine 7.5KW 0





Following Type Pesticide Filling Machine Features:



Double servo motors structure are adopted to lift filling mechanism. Ensure
the accuracy.

Liquid Detergent Pesticide Filling Machine 24 Bpm Bottle Filling Machine
Solvent Filling Machine 7.5KW 1



Filling machine liquid tank bottom is arc design, to ensure that the liquid
discharge clean, no dead angle, no liquid accumulation

Liquid Detergent Pesticide Filling Machine 24 Bpm Bottle Filling Machine
Solvent Filling Machine 7.5KW 2



Cylinder off structure, which can completely empty the materials in the
cylinder, effectively avoiding the cross contamination

Liquid Detergent Pesticide Filling Machine 24 Bpm Bottle Filling Machine
Solvent Filling Machine 7.5KW 3
