Membrane Filtration (Coated Filter Element)

Membrane Filter Element Porous Metal Filters Supplier

The membrane filtration product of Jintai Company is a kind of surface
filtration. The surface of this product has a very thin precision filter layer,
and the inside is a high-strength support layer. The two layers are sintered at
high temperature to form a chemical bond, so the filter layer will not fall off
even under harsh working conditions. The Jintai membrane filtration product has
low pressure loss during filtration and has a good anti-cleaning effect, which
can greatly extend the service life of the filter element.

Features of Membrane Filtration
Surface filtration
Lower pressure difference
Good regeneration performance
Longer service life

Specifications
Material selection Stainless steel: 316L 304L
Other materials required by the customer
Filtration Grade 0.1um 0.3um 0.5um 1um 3um
Other grade required by the customer
Data & Specifications Length: The longest seamless tube is 1600mm
Diameter: 25-64mm
Other specifications and sizes required by customers
Connection Thread, flange, flat pressing, quick connection, etc.
Other ways required by customers

Typical Application
Impurity filtration and precision filtration of petrochemical products
Filtration and recovery of crystals and catalysts, solvent recovery
Gas-solid separation, solid-liquid separation in high temperature and corrosive
conditions
Gas purification
Sterilization and filtration in medicine and other fields
