Nanofiltration Systems

Nanofiltration systems offer advanced water purification technology that
bridges the gap between ultrafiltration and reverse osmosis. Nanofiltration
(NF) functions similarly to reverse osmosis, but is typically used to remove
only divalent and larger ions. Monovalent ions such as sodium and chloride will
pass through the nanofiltration membrane, so many of its uses involve
desalination of process streams. Their performance ensures ultra-purification,
making them suitable for a variety of industrial and municipal applications.
Applications
Industrial Water Treatment: Used in processes requiring high-purity water, such
as in the chemical and pharmaceutical industries.
Municipal Water Supply: Helps improve water quality by reducing contaminants
without stripping beneficial minerals, making it ideal for drinking water
applications.
Wastewater Reuse: Contributes to water recycling and conservation efforts by
treating and purifying wastewater for reuse.
Spcification
SKSS-NF-1T Nanofiltration equipment
Equipment external dimensions （1500mm/750mm/1920mm）
Equipment treatment process Raw water - Raw water pump - Mechanical filter
- Activated carbon filter - Add scale inhibitor
-Precision filter - NF high pressure pump - NF nanofiltration membrane element
- finished water
Control mode Fully automatic operation Equipment power supply
AC/380V/50HZ
Unladen weight 325KG Operating weight 650KG
Raw water pump Q=2m³/H
H=30m High pressure pump Q=2m³/H
H=110m
Quartz sand filter φ300×1650mm Activated carbon filter φ300×1650mm
Precision filter 5 pole 20 inch Precision filter element 20
inches 5 microns
Scale inhibitor dosing pump Q=1L/H
H=50m Scale inhibitor dosing tank 40L
