New road/warning/traffic sign CNC corner forming machine no welding no grin

*This machine is used in the processing of sheet metal corner moulding such as
cold-rolled plate ,aluminum plate ,stainless steel plate ,copper plate etc.
*Widely used in the switching door ,cover plate ,aluminum single panel curtain
wall , switchboard ,container cover, household appliances ,instruments and other
Technical Features
*The forming and shearing is finished separately in two working position ´╝Ť
*Install safety light curtain protection to make the production process more safe
and humanistic´╝Ť
*The accuracy of different thickness is controlled by Fuji servo motors;
*Parameters is adjusted through touch screen, some other movement is controlled by
Mitsubishi PLC.A set of mould is with the machine ,including :rolling mould
,square mould ,shear knife of a corner radius.
*Adopt the imported first-class brand components as our key electrical components
to ensure the reliability and stability of the system.
*The PLC controller with 68 points can store and save lots of sheet metal corner
moulding technologies, gap compensation coefficients .At the same time ,it can
save and rewrite the coefficients of special materials and even the complex
bimetal at any time
*This machine improves work efficiency more than three times by changing the
tedious process of open-angle welding ,grinding etc into rolling ,stretching and
forming directly .it saves labor ,electricity ,gas ,grinding material and other
accessories for enterprises, therefore ,it is both environmentally friendly and
greatly reduces the production cost , could be regarded as the enterprise save-
money expert.

Minimum Order: 1 sets

New road/warning/traffic sign CNC corner forming machine no welding no grin
