Refrigeration enclosure CNC corner forming machine

*The machine owns twin shear function，the integrated shearing and forming
function can be chosen in mass production ,the corner can be formed and sheared
without changing shearing position ,saving physical capability .when the
production is of great variety ,in small batch ,the separated forming and shearing
function can be chosen . when the flange height is below 30mm, the flange height
can be flexible and changeable ,the workpiece can be finished directly just change
the station to shear after the corner isformed. This machine is one of the most
advanced models in the world recently.

*Install safety light curtain protection to make the production process more safe
and humanistic .

*Adopt the imported first-class brand components as our key electrical components
to ensure the reliability and stability of the system.

*The PLC controller with 68 points can store and save lots of sheet metal corner
moulding technologies, gap compensation coefficients .At the same time ,it can
save and rewrite the coefficients of special materials and even the complex
bimetal at any time

*This machine improves shearing efficiency more than six times by changing the
tedious process of open-angle welding ,grinding etc into rolling forming directly
.it saves labor ,electricity ,gas ,grinding material and other accessories for
enterprises, therefore ,it is both environmentally friendly and greatly reduces
the production cost , could be regarded as the enterprise save-money expert.

Minimum Order: 1 sets
