PM2.5 Purification dX AHU AC Industrial Air Handling Unit 380v

Product features

KD(X) series ceiling air conditioning unit is a hoisting air treatment unit at
the end of central air conditioning unit, which can filter, cool, dehumidify,
heat and introduce fresh air.

It is suitable to send the treated air to the place with a certain distance
through the air pipe. It is especially suitable for the air conditioning
engineering of small commercial and industrial buildings.

Unit installation

The ceiling type air conditioning unit shall be installed horizontally, and the
condenser water pipe side shall be allowed to be on the low side by 5%, but not
on the high side, so as to ensure the smooth discharge of the condenser
water.Sufficient installation and maintenance space shall be reserved around
the unit

Condensate discharge connected to the unit shall be provided with a water seal
with sufficient height

The water connection pipe of the surface cooler is bottom in and top out, and
the globe valve and filter should be installed at the water inlet

The flexible connection of the air pipe with the unit, the water pipe with the
unit should be flexible pipe, the torsion force should not be too large when
the pipe is connected to the unit, so as not to damage the heat exchanger, the
pipe should have a separate home, the weight should not be borne by the unit.

The power supply of the unit is 380V and 50Hz.Only when the power supply meets
the requirements can it be connected to the motor. After being connected to the
power supply, check whether the fan's steering is correct. If the power supply
is reversed, stop the machine to change the phase sequence of the power supply.

The fan motor shall be well grounded and shall be provided with overload,
overheating, missing items and other reliable protection devices.
