Prestressed Concrete Steel Wire Spiral Ribbed

PC Wire (also referred to as Prestressed Concrete Steel Wire) is high tensile,
low relaxation steel wire made from high-carbon steel and widely used for
prestressed and post-tensioning technology in various shapes of PC structures.
It has the following characteristics and advantages:
● High tensile strength and low relaxation
● More bonding stress between wire and concrete.
● Stable modulus of elasticity.
Prestressed Concrete Steel Wire Properties:
Product Name PC Wire(Prestressed Concrete Steel Wire)
Type of Surface Spiral Ribbed, Indented, Plain
Materials SWRH82B
Diameter 4.0mm, 4.8mm, 5.0mm, 6.0mm, 7.0mm, 8.0mm, 9.0mm
Surface treatment Uncoated prestressed steel wire, prestressed epoxy
coated steel wire and galvanized prestressed steel wire.
Tensile Strength 1470Mpa-1770Mpa
Relaxation (%) ≤2.5
Elongation (%) ≥3.5
Standard ASTM A 421, GB/T5223, BS5896, JISG3536, and required standard.
Packing Packed in coils (around 700-1300kg/coil). Each coil is strapped by
steel bands at 8 places, fully wrapped with anti-rust plastic & PP woven sheet.
Prestressed Concrete Steel Wire Application PC Wire is characterized with
high tensile strength and low relaxation. It's widely used in production of
prestressed spun concrete poles, PHC Piles, in construction of large scale
railroad, high-way bridges, building trusses, overhead crane beams, industrial
and civil prefabricated concrete slabs, wall board, power station, etc.
