PVC Air Hose

Pvc Air Tube

Characteristics: light –weight, wear resistance, erosion resistance, good
flexibility
Working Temperature: -5°C-65°C
Contact Us
PVC air hose is made of tough PVC materials and high tensile polyester
reinforcement,it can work under very high pressure.

Apply to: some pneumatic tools, pneumatic washing apparatus, compressors,
engine components, machinery service tools, pesticide spraying apparatus and
civil engineering pneumatic hammers

Specifications of PVC Air Hose
Item No. Type Hose dimension WP BP
I.D O.D Wall
Inch mm mm mm BAR BAR
PVCAIR-0611 1/4" 6 11 2.5 15 60
PVCAIR-0612 1/4" 6.5 12 2.75 20 60
PVCAIR-0814 5/16" 8.5 14 2.75 20 60
PVCAIR-1016 3/8" 10 16 3 20 60
PVCAIR-1320 1/2" 13 20 3.5 20 60
PVCAIR-1625 5/8" 16 25 4.5 20 60
PVCAIR-1928 3/4" 19 28.5 4.75 17 52
PVCAIR-2534 1" 25 34.5 4.75 16 48
PVCAIR-3244 1-1/4" 32 44 6 15 46
PVCAIR-3850 1-1/2" 38 50 6 15 45
PVCAIR-5064 2" 50 64 7 10 30

SEAPEAK is one of the professional hose manufacturers and rubber pipes
suppliers, we provide pvc air compressor lines, pvc air compressor hose, heat
proof rubber hose and etc. Want to know more? Please contact us.
