PVC & PVG Conveyor Belt core flame retardant conveyor belt

PVC & PVG Conveyor Belt core flame retardant conveyor belt reinforced
rubber belting

PRODUCT DESCRIPTION
Baoxiang PVG Conveyor Belt Specification
Type Tensile strength/ N/mm, ≥ Breaking elongation/ %, ≥
Top/bottom cover/mm, ≥
Longitudinal Transversal Longitudinal Transversal
680S 680 265 15 18 1.5
800S 800 280
1000S 1000 300
1250S 1250 350
1400S 1400 350
1600S 1600 400
1800S 1800 400
2000S 2000 400
2240S 2240 450
2500S 2500 450

PVC Conveyor Belt
Specification
Type Tensile strength/ N/mm, ≥ Breaking elongation/ %, ≥
Top/bottom cover/mm, ≥
Longitudinal Transversal Longitudinal Transversal
680S 680 265 15 18 1.0
800S 800 280
1000S 1000 300
1250S 1250 350
1400S 1400 350
1600S 1600 400
1800S 1800 400
2000S 2000 400
2240S 2240 450
2500S 2500 450

Safety performance
Name of the performance Alcohol burning Propane burning Different electric
performance Roller friction
Standard value Average value≤3S, single value≤10S (with cover glue) ≧250mm
≦3x10 8 Ω ≦325°C
Average value≤5S, single value≤15S (with cover glue)
No mars

The whole core flame retardant conveyor belt is made of the whole belt core
impregnated by PVC impregnated paste plasticization or vulcanization, with
large strength, large volume, transport balance and other characteristics, and
the product has good flame retardant, antistatic, impact resistance, wear
resistance, corrosion resistance and other properties.
The whole core flame retardant conveyor belt is mainly used in underground coal
mine, but also for material transportation in metallurgical and chemical
industries.The belt features: no delamination, small elongation, impact
resistance, tear resistance.According g to the different knots can be divided
into PVC type (plastic surface), PVG type (on the basis of PVC with rubber
surface) whole core flame retardant tape.
PVC upper and lower covering layers shall be PVC cover adhesive, single side
adhesive ≥ 0.8mm, PVG upper and lower covering layers shall be both nitrile
butadiene rubber and PVC, and the single thickness shall be 1.5mm-4.5mm
PVC conveyor belt transport dip Angle <16°, PVG conveyor belt transport dip
Angle <20°, can be used in coal mines, underground transport.

Baoxiang is a multifunctional conveyor belt manufacturers that integrates
production line development, manufacturing, debugging and technical
transformation. Its products include conveyor belting, nylon conveyor belt,
etc.
