Radar RD03

The RD03 low-altitude surveillance radar is a Ku-band phased array radar that
adopts an all-solid-state, all-coherent pulse Doppler system. The target update
rate can reach 3 seconds, allowing for all-weather detection and tracking of
fast-moving "low, small, and slow" targets. This radar adopts
azimuth mechanical scanning and elevation
electronic scanning methods, offering higher cost-effectiveness compared
to two-dimensional phased array and multi-beam radars.
Parameter Index
Frequency Band Ku-band
Detection Distance ≥12km（RCS=0.01m²）
Blind Spot 200m
Angle Coverage Azimuth：0°~360°， Elevation：0°~30°
Tracking Function Supports target tracking
Speed Range 1m/s~100m/s
Scanning Method Azimuth：Mechanical scanning，Elevation，phase scan
Accuracy Distance＜10m， Azimuth：＜0.5°，Elevation：＜0.5°
Targe , t Update Rate 6s/3s
Port Network port
Weight ≤35g
Powered By AC220V
Power Consumption ≤1300W
Radar RD03
