Road simulation Sand Dust Test Chamber ISO 20653

Application
blowing sand and dust test chamber is capacity of 1000 liters. Considering
that some specimens are smaller, following the marketing demand and customer
required that we designed and produced this small sand and dust chamber.

Feature
ASTM B117 chamber dust sand test chamber dust proof chamber is made for
the simulation of dust and sand conditions. These sand and dust chamber used to
test the exposure of test the exposure of automotive and electronic components
under extreme environmental conditions in order to validate product seal.Dust
ingress test methods included IEC60529, ISO20653 and many others.

The airflow circulates upward from the bottom, blowing the dust
circulation,forcing dust around the specimens. All models are upgrade to
programmable controller and Ethernet access that provides simple operation and
control.If you need more models about our test equipment, please reference our
https://www.chamber-testing.com/

Blowing sand and dust test chamber door attached to the window, the door to the
lower part of the electrical control area,Simulated sand dust of talc in the
lower hopper of the test chamber. Use the of circulating fan and automatic jar
will be blown into the upper network studio talcum powder through a 75 micron
square hole,The test space form high density dust shape, test specimen.

Technical Specifications
Concentration: Adjustable 1–20 g/m³ (±0.5 g/m³ precision).

Temperature Range: -30°C to +80°C (±2°C stability).

Airflow Velocity: 1–20 m/s (variable for static/dynamic testing).

Volume: 0.6 m³ (standard) to 2.5 m³ (custom), with reinforced acrylic
observation windows.

Test Duration:Programmable cycles (1–999 hours), IP5X/IP6X compliance modes.

Minimum Order: 1 pieces
