RS232 Security Turnstile Gate With Face Recognition Card System QR Barcode

Product Description
Face Recognition Card System Qr Barcode Reader Security Turnstile



Turnstile Gate Features

1. 304 stainless steel: Anti-rust, wear-resistant, high temperature resistant,
and corrosion resistance

2. Molded Tripod Turnstile Mechanism: Die-cast aluminum integral molding,
special paving treatment

3. Pedestrian passage gate main board: Dynamic arrow lights guide traffic, Dry
contact signal, Support fire signal access, Memory mode



Turnstile Technical Parameters

Model

WJTS211

Mate , rial of Housing

304 Stainless Steel

Dimension of Housing

420*330*980mm

Length of Pole(out of housing)

495mm

Net Weight

50kg

Input Voltage

220VAC±10%, 110VAC±10%

Motor Power

50W


Tripod Turnstile Gate Functions

1. It can be integrated with any kinds of access control system, such as RFID
device, push button, fingerprint, biometric, card swallowing machine and so on.

2. Bi-direction pass/any single direction pass (adjustable).

3. Arm auto-drop when power off, and auto rise up when power on.

4. Traffic light indicator.

5. Alarm light, remote control, counter are available.

6. RS232 socket available which can connect to computer control.



RS232 Security Turnstile Gate With Face Recognition Card System QR Barcode
Reader 0

Click to Enlarge
