Stainless Steel Wire Mesh

ZhongPu Wire Mesh Co., Ltd. offers customized stainless steel wire mesh
products in a wide range of special specifications. Customers with specific
requirements are welcome to contact us at any time.

Our recent customized specifications are as follows:

40 Micron Stainless Steel 316 Wire Mesh for Air Filtration
Micron stainless steel wire mesh is a fine-aperture filtration medium
manufactured with precision wire and uniform openings. It is commonly used for
air filtration and is available as woven micron wire mesh and sintered micron
wire mesh.

Materials: stainless steel grades 201, 202, 304, 304L, 316, 316L, 321, 430
Standard Sizes: roll width 1.0 m to 1.22 m (40–48 inches), roll length 30 m to
100 m, mesh count 1–635 mesh, wire diameter 0.05–1.50 mm (commonly 0.25–0.80
mm)
Weave Structures: plain square weave, twilled square weave, plain Dutch weave,
and twilled Dutch weave are available to meet different filtration accuracy and
airflow requirements.
Sintered Micron Mesh: multi-layer sintered wire mesh is produced by compressing
and vacuum-sintering 2–12 layers of stainless steel wire mesh. The filtration
rating ranges from 0.5 micron to 300 microns, providing higher strength and
stable filtration performance.
316 SS Wire Mesh, 50 micron mesh size, in a roll width of 36” at 25 ft. long
Mesh Size: 50 micron filtration rating for fine particle filtration
Roll Dimensions: roll width 36 inches (914 mm), roll length 25 feet (7.62 m)
Material: 316 stainless steel wire mesh offering corrosion resistance and
consistent filtration performance
