TBP-06 Insulated Cable stripper

This product is a specialized stripping device developed for various wire diameters
of
insulated wires currently in use in China. The product has a simple structure,
modular
design, and can be operated by a single person. By changing the direction of the
handle, functions such as embedding wires, peeling, and exiting peeling can be
achieved. By replacing the operating lever, it can be applied to both power-off and
live working operations.
1. Components and standard configurations
Specification Name Function contain
TBP-06 Insulated Cable Fixed cutting tools and connecting One Stripper
Stripper operating rods to complete the
peeling function
TBP-15 Operating 1.5m insulated hot stick for use One hot stick
tools in arm truck operations (Choose one)
TBP-25 Operating 2.5m insulated hot stick for use in One hot stick
tools ground potential operation method (Choose one)
TBGX-01 Storage box Storing stripper racks and One box
corresponding tools
2. Technical Data
Applicable cable: Cross linked polyethylene insulated wire, cross-section 50mm2-
240mm2 (special cable types can be customized)
Peeling operation: single person operation;
character of operation: Live working of bucket arm truck: TBP-15 type operating rod
can be used for stripping operation on power outage lines;
Ground potential live operation: TBP-25 type operating rod can be used for live
stripping operation on the operating line.
Working voltage: 10kV in non rainy and snowy environments
3.Ordering instructions: When selecting the product, please specify the nature of
the operation (power-off operation/live operation) and provide the specific model of
the insulated wire (with different thicknesses of the insulated wire skin), in order
to select the appropriate tool holder. After the tool wears out slowly, you can
grind it yourself or order a new tool.

Minimum Order: 1 pieces
