TF-III Infusion Warmer is a ‘dry heater’, which does not directly contact the
heated liquid in working process.
It transfers heat from heat exchanger through infusion tube to liquid in the
pipe to achieve the purpose of continuous heating to flowing liquid. The
operator can adjust the setting temperature in the range of 35°C - 42°C
according to actual needs, and the heater can automatically work to the preset
temperature with the built-in intelligent chip and maintain the constant
temperature state after reaching the target temperature.
SPECIFICATIONS
Device Dimension: 180mm x 70mm x35mm
Weight: ≈0.2KG (without knob); 0.4kg (with knob)
Display Type: Led
Applicable IV set: Exclusive IV Set or standard single PVC IV Set (20 and 60
d/mL, with outer diameter 3.4 ~ 4.5mm)
Temperature Range: 35°C~42°C (95~107.6F), 0.1 °C increment
Optional Unit: (°C) and (°F)
Temperature Accuracy: ±1°Cor±1.8°F
Warning up time: <2min
Overheat Protection: 48°C
Alarm: Overheat, low temperature, system error, door open, heating reminder
Input Voltage: 100-240V
Frequency: 50Hz/60Hz
Power: 85VA
