VMC-856 HIGH SPEED 3 AXIS GANTRY VERTICAL MACHINING CENTER

The VMC-856 High Speed 3 Axis Gantry Vertical Machining Centers are high-
performance, high-stability CNC machines specifically engineered for high-
precision milling, drilling, tapping, and boring of complex components.
Featuring a modular design, this series offers excellent rigidity and dynamic
performance, capable of handling a wide range of machining needs—from small
and medium-sized parts to large workpieces. The VM series Vertical Machining
Center is widely used in industries such as mold making, aerospace, automotive
manufacturing, and energy equipment production.
Advantages of VMC-856 Vertical Machining Center
High-Rigidity Structural Design:
The machine base is made from high-quality cast iron and optimized through
finite element analysis (FEA) for superior vibration resistance and thermal
stability. All three axes utilize high-precision linear guides, with the Z-axis
equipped with a counterbalance system to minimize vibration during high-speed
operation, ensuring long-term machining accuracy.
High Precision and Dynamic Performance:
Repeatability: ±0.003 mm per 300 mm, ideal for precision mold making and
complex surface machining.
Spindle speed ranges from 8,000 to 12,000 RPM with high torque, suitable for
both heavy-duty roughing and high-speed finishing.
Smart & Automation Ready:
Equipped with the latest CNC systems (Mitsubishi, FANUC, or advanced domestic
controllers).
Optional support for 4-axis or 5-axis simultaneous machining (with optional
rotary table).
24-tool Automatic Tool Changer (ATC) with a 1.4-second tool change time for
enhanced continuous machining efficiency.
Integrated automation interfaces for robotic arms or conveyor systems, enabling
fully unmanned operation.
Specifications
Item unit VMC-856
Worktable area mm 1000*550
Worktable maximum loading kg 600
T-Slot(slot*width*distance) mm 5-18*90
Spindle nose taper BT BT40
XX/Y/Z axis travel mm 800/560/560
Distance between spindle end face and worktable end face mm 120-670
Specifications of X, Y and Z axle guideways mm 35/45/45
Spindle Speed (Belt type/Direct Connection) rpm 10000/12000
Tool magazine capacity T 24
X/Y/Z axis fast displacement m/min 48*48*48
Cutting feed speed m/min 1-8000
