2-Transmitter 8-Receiver RFSOC Airborne Phased Array Radar Signal Processin

IW-ZU27DR-2T8R is an algorithm evaluation board based on the Zynq UltraScale +
RFSoC ZU27DR main chip (high-speed ADC and DAC are integrated inside the IC),
supporting multi-board cascading. It provides a COTS solution that can provide
the advantages of RFSoC while more effectively offloading data and enjoying the
benefits of COTS: users get the fastest possible deployment while taking
advantage of lower cost of ownership, lifecycle support and simplifying future
technology insertion. This product supports 8-channel 12-bit ADC 4.096 GSPS and
8-channel 14-bit DAC 6.4 GSPS.
Product Features
Miniature design: 130mm×80mm size, weight less than 200g, 2 transmitters and
8 receivers, external J30J-21 and J30J-9 interfaces;
Low power consumption: overall power consumption is less than 30 watts;
Low latency: remove the high-speed serial interface between JESD204B analog
and digital, greatly reducing system complexity and latency;
RF direct acquisition: can directly acquire any IF signal within DC-4GHz in 8
channels, with a maximum instantaneous acquisition bandwidth of 2GHz;
