IW-RFSOC-48DR-SYN Mixed Signal Processing Card

IW-RFSOC-48DR-SYN digital-analog mixed signal processing card, using Xilinx
ZYNQ UltraScale + RFSoC ZU48DR, can access large FPGA gate density, 8 ADC/DAC
ports, expandable I/O ports and DDR4 memory, suitable for a variety of
programmable applications, IW-RFSOC-48DR-SYN with ZU48DR FPGA is supported by 8
14-bit, 4GSPS sampling rate ADC and 8 14-bit, 9.85 GSPS sampling rate DAC
ports. ADC and DAC ports are supported by high-performance micro RF connectors.
IW-RFSOC-48DR-SYN is equipped with a high-pin count FPGA mezzanine card (FMC+)
compliant with the Vita 57.4 standard and a large number of daughter card
options to support extended functionality. It can provide a comprehensive RF
signal chain to meet the demands of machine learning or optical
wireless applications, such as Massive-MIMO remote radio units, millimeter
wave mobile backhaul, 5G baseband, fixed wireless access, early warning/radar,
wired Remote-PHY nodes, test and measurement, satellite communications and
other high-performance RF applications.
