7" x 1 1/4" Trailer Electric Brake Assembly

√

Trailer Torsion axle

√

Manual Adjustment

√

7 x 1.25 inch drum

√

2200 lbs trailer axle

√

7" electric drum brake

√

7'' electric backing plate

7’’ trailer brake assemblies are usually installed to torsion axles with
max capacity of 2.2k lbs . These brakes are mostly for light trailers which
axles do not need leaf springs.

Features

l 7 inch electric brakes are easy to install and control.

l Needs only an electric brake controller to work.

l E-coated backing plates resist corrosion.

l Periodic manual adjustment required.

l Brake mounting bolts are included.

l Exchange with most trailer axles not over 2200 lbs, including Dexter,
AL-KO and many others.

Specifications

Ø Dimension: 7 inch x 1 1/4 inch

Ø Axle Capability: 2200 lbs Axle

Ø Mounting Flange Bolt Pattern: 4 bolts

Ø Brake Fit: Left Hand / Driver Side / LH, Right Hand / Passenger Side /
RH

Product Composition

Ø 7” x 1 1/4" Brake Shoe Set x 1

Ø E-coat Backing Plate x 1

Ø Round Magnet with White Wire x 1

Ø Magnet Lever x 1

Ø Returning Springs x 1

Ø Adjuster x 1

Minimum Order: 300 pieces
