70VA Isolation Electronic Toroidal Auto Transformer 230VAC To 24VAC

Features



1).A toroidal transformer weights and temperature rise about half as much as
conventional transformer with the same capacity.

2).No impregnation is needed to keep the laminates quiet so this potential
environmental hazard is avoided.

3).The toroidal transformer fits into a smaller space, which allows chassis
plates and enclosures to be smaller with less material used.





Specifications

Item Description
Capacity 70VA
Frequency 50/60Hz
Max. Temperature 60℃
Temperature rise <60℃
Insulation class B/F
Voltage ratio 230VAC-24VAC
Winding material Copper
Insulation Resistance PRI.-SEC.: 500V DC 100 MΩ/Primary to Secondary 500VDC
100MΩ Min.
Short-Circuit of winding turn PRI. Iput: 440V AC 150HZ/ Primary and Secondary
Not break down)
Hi-Pot Test PRI.-SEC.: 4.2KV/5mA/2S / Primary and Secondary Not break down
)
Mounting metal plate Provided
Rubber gasket Provided
Standards VDE0550/IEC204-1/IEC61558/EC439
Warranty 24monthes
