AAGW210-10 Alternating Winding Machine

Specifications：
Spindle number:10
Wire size range:0.1-0.55mm
Loop diameter:Φ75mm
The max wire spacing:9.99mm
Winder width:75mm
Max speed:0-4500 RPM
Spindle motor:1.5KWAC motors
Winder motor:Stepping motor
Control mode:PLC and stepper motor drive system
Winder direction:Adjustable at both ends
Input power:220V,60/50Hz
Machine size:1480×900×1580mm
Package size:1500*90*150mm
Weight:219kg

Features , ：
The installation of disconnection detection, front and rear machine limit
device.
The Alternating Winding Machine has special winding fixture design, to
prevent loosening.
Alternating Winding Machine Using of high-precision magnetic tension
device, the winding effective more better.
Alternating Winding Machine can Winding 10 products at the same time
, realize the real efficient.
With auto flip function,to achieve change bobbin and winding at the same
time.

Advantages：
This Alternating Winding Machine adopts PLC touch screen imported from
Taiwan, Taiwan (TBI) ball screw and guide rail ,Japan bearings (NSK), Japan
BANDO belt.
Machine with thick cast iron box, with high-power three-phase AC motor
torque at low speeds greater, with full English and Chinese display.
Operation and set parameters is more simple and convenient, high speed,
accurate positioning, so that customers in the course of truly experience
the saving time, labor, and high efficiency.

APPLICATION:
Automatic Coil winding Machines are used for winding the small EI
transformers, signal transformers, inductors, filter choke coil, relays,
current contactors, valve coils, solenoid coils, telecom bobbin
transformers. It can complete the coils without any one operator in fully
automatically.

PRACTICAL APPLICATION :
TRAINNING CUSTOMER TO OPERATE WINDING MA , CHNE :
1.All service engineers with 10 ye ,
ars experience are gotten special technol ,
, ogy training, who can deal with various bre , akdown problem.
2.Guide the user to use a , ccurately and how to maintain the Alternatin ,
g Wind
ing Machine.
Provide free consultation about pr ,
oduction process technology of electronic< , br>

Minimum Order: 1 pieces
