BS Standard Cable

BS Standard Cable
Product Description
Single core cables with solid or stranded copper conductors, PVC insulated,
rated 450/750V conforming to SASO:55 specification
Construction:
Conductor
Pla , in annealed circular copper conforming to IE , C:228, class 1 and 2 (
also available in aluminum conductors sizes 16 to 630 mm2).
Insulation
PVC type 5 to BS:6746  , rated 85°C, (PVC type 1 to BS:6746 rated  , 70
°C also available)
Application: Typical applica , tions include building wiring, equipment wiri ,
ng, switching and distribution installations in conduits above or under
plaster
Features: Insulation adheres tig , htly to conductors yet strips easily,
leaving conductor clean. PVC insulation has good electrical properties.
Dimensions and Weights
Conduct , or Insulation Packaging
Cross sectional area
Nominal Minimum number
of wires Thickness Nominal Overall diameter
Approx Net weight
Approx B-Box, S-Spool
C-Coil, D-Drum
m m2   m m m m kg/km m
1.5 re 1 0.7 3.0 19 50/100 B/S
1.5 rm 7 0.7 3.2 19 50/100 B/S
2.5 re 1 0.8 3.6 30 50/100 B/S
2.5 rm 7 0.8 3.8 31 50/100 B/S
4 re 1 0.8 4.1 47 50/100 B/S
4 rm 7 0.8 4.3 48 50/100 B/S
6 re 1 0.8 4.6 66 50/100 B/S
6 rm 7 0.8 4.9 67 50/100 B/S
10 re 1 1.0 5.9 110 50/100 C
10 rm 7 1.0 6.3 113 50/100 C
