ASTM A285 Grade C Pressure Vessel Carbon Steel Plate - SHH STEEL

ASTM A285 Grade C Pressure Vessel Carbon Steel Plate - SHH STEEL

1. Product Introduction
SHH STEEL, a China Mill-Direct Exporter, supplies ASTM A285 Grade C
(A285 Gr C) carbon steel plate for pressure vessels. Higher strength
than Grade B with good weldability. Applications: Pressure Vessels,
Storage Tanks, Boilers, Heat Exchangers, Oil & Gas, General
Fabrication. Specification: ASTM A285 / ASME SA-285 — Delivery: As-
rolled (AR) or normalized (N). Equivalent Grades: ASTM A285 Gr C /
JIS SB450 / GB Q245R / ISO P245GH. Thickness: 6 mm – 300 mm
(thicker available). Width: Up to 3000–4000 mm / 12000–18000 mm.
As a professional steel plate supplier and China Mill-Direct
Exporter, SHH STEEL is pleased to present ASTM A285 Grade C Steel
Plate (also known as A285 Gr C or A285 Grade C,ASTM A285GRC). ASTM
A285 Grade C is a carbon steel plate of intermediate tensile strength
designed for fusion-welded pressure vessels, boilers and storage
tanks. Among the three grades in the A285 specification, Grade C
provides the highest strength while still offering excellent
weldability and good formability.

2. Standards We Can Supply
ASTM A285 / ASME SA-285 — Delivery: As-rolled (AR) or normalized
(N). Equivalents: ASTM A285 Gr C / JIS SB450 / GB Q245R / ISO P245GH.

3. Grades We Can Supply
ASTM A36/SA36, A283 Gr.C, A285 Gr.C, A515 Gr.70, A516 Gr.60/70
(SA516), A537 Cl.1, A572 Gr.50/60, A387 Gr.11/22 Cl.2, A514 Gr.Q, EN
10025-2 S355J2.

4. Size Range
Thickness: 6 mm – 300 mm (thicker available). Width / length: Up to
3000–4000 mm / 12000–18000 mm.

5. Processing
Flame/plasma cutting to size or drawing, cut-to-length, bending and
forming, welding and CNC machining services.

6. Delivery Time
Stock: 5-6 days. Normal production: 30-40 days.

7. Payment Terms
T/T and L/C accepted; specific payment terms are negotiated per
order.

8. Trade Terms
FOB / CIF / CFR.

9. Delivery Condition
As-rolled (AR) or normalized (N).

10. Quality Assurance
Mill test certificate supplied.

11. Company Capability
SHH STEEL (Shanghai Shenghonghe Import & Export Co., Ltd.) is a China
mill-direct steel exporter serving manufacturing, energy,
construction, marine, petrochemical and machinery industries, with
custom sizes and in-house cutting, forming, welding and machining.
Export seaworthy packing.
