1. Product Introduction
SHH STEEL supplies ASTM A514 Grade Q / A514 Gr.Q 100 ksi QT
structural plate worldwide, 690 MPa yield to 65 mm. EN 10204 3.1/3.2
mill-direct supply. Applications: Crane and boom, Mining and
earthmoving, Trailers and chassis. ASTM A514 Grade Q, also searched
as A514 Gr.Q, A514GRQ, A514-Q, A514Q, T-1 Grade Q and 100 ksi QT
plate, is the thick-plate grade in ASTM A514/A514M. That book covers
quenched-and-tempered alloy structural plates intended primarily for
welded bridges and other structures. Maximum thickness for Grade Q is
6 in / 150 mm. General requirements follow ASTM A6 / ASME SA-6, not
A20 / SA-20. There is no ASME SA-514 / SA-514M book in current
Section II, Part A. Inquiries that write SA514 Gr.Q are still buying
ASTM A514 Grade Q. Code quenched-and-tempered vessel plate is ASTM
A517 Grade Q, not A514. This page is not A572 Gr.50. A572 is Nb-V
HSLA in the as-rolled or normalized condition. This page is not EN
10025-6 S690QL. S690QL is a European QT comparison, not an automatic
swap. Tensile and yield change with thickness. To 2½ in / 65 mm,
yield is 100 ksi / 690 MPa min and tensile is 110–130 ksi /
760–895 MPa.

2. Standards We Can Supply
ASTM / ASME.

3. Grades We Can Supply
ASTM A36/SA36, A283 Gr.C, A285 Gr.C, A515 Gr.70, A516 Gr.60/70
(SA516), A537 Cl.1, A572 Gr.50/60, A387 Gr.11/22 Cl.2, A514 Gr.Q, EN
10025-2 S355J2.

4. Size Range
Sizes per order; contact us for available range.

5. Processing
Flame/plasma cutting to size or drawing, cut-to-length, bending and
forming, welding and CNC machining services.

6. Delivery Time
Stock: 5-6 days. Normal production: 30-40 days.

7. Payment Terms
T/T and L/C accepted; specific payment terms are negotiated per
order.

8. Trade Terms
FOB / CIF / CFR.

9. Delivery Condition
As-rolled or as specified by the standard.

10. Quality Assurance
Mill test certificate supplied to EN 10204 3.1/3.2 as stated for this
grade.

11. Company Capability
SHH STEEL (Shanghai Shenghonghe Import & Export Co., Ltd.) is a China
mill-direct steel exporter serving manufacturing, energy,
construction, marine, petrochemical and machinery industries, with
custom sizes and in-house cutting, forming, welding and machining.
Export seaworthy packing.
