1. Product Introduction
ASTM A516 Gr.60 carbon steel plates are high-strength, perfect for
pressure vessels and boilers. With 415-550 MPa tensile and 220 MPa
yield, they suit 400°C, 300 bar use per ASME Section VIII, globally
supplied by SHH STEEL. Applications: Pressure Vessels, Boilers,
Storage Tanks, Oil & Gas Equipment, Heat Exchangers. Specification:
ASTM A516/A516M-17 for pressure vessels and boilers. Equivalent
Material: P295GH (EN10028-2), SPV315 (JISG3115), 16MnR/Q245R
(GB/T713). Dimensions: 5-500mm thick, 4600mm max wide, 12000mm max
long. Hardness/Density: A516 GR 60 Hardness 120-170 HB, Density 7.85
g/cm³. As an expert at SHH STEEL, I’m proud to introduce our ASTM
A516 Grade 60 Carbon Steel Plates, also known as ASTM A516GR60 or
ASTM A516 GR 60. These plates are a go-to choice for pressure vessels
and boilers, offering a robust balance of strength and weldability.
With a tensile strength of 415-550 MPa and a minimum yield strength
of 220 MPa, they’re designed to handle pressures up to 300 bar and
temperatures around 400°C, meeting ASME Section VIII standards.

2. Standards We Can Supply
ASTM A516/A516M-17 for pressure vessels and boilers. Equivalents:
P295GH (EN10028-2), SPV315 (JISG3115), 16MnR/Q245R (GB/T713).

3. Grades We Can Supply
ASTM A36/SA36, A283 Gr.C, A285 Gr.C, A515 Gr.70, A516 Gr.60/70
(SA516), A537 Cl.1, A572 Gr.50/60, A387 Gr.11/22 Cl.2, A514 Gr.Q, EN
10025-2 S355J2.

4. Size Range
Thickness: 5mm-500mm (custom). Width / length: Up to 4600mm /
12000mm.

5. Processing
Flame/plasma cutting to size or drawing, cut-to-length, bending and
forming, welding and CNC machining services.

6. Delivery Time
Stock: 5-6 days. Normal production: 30-40 days.

7. Payment Terms
T/T and L/C accepted; specific payment terms are negotiated per
order.

8. Trade Terms
FOB / CIF / CFR.

9. Delivery Condition
Normalized (N).

10. Quality Assurance
Mill test certificate supplied.

11. Company Capability
SHH STEEL (Shanghai Shenghonghe Import & Export Co., Ltd.) is a China
mill-direct steel exporter serving manufacturing, energy,
construction, marine, petrochemical and machinery industries, with
custom sizes and in-house cutting, forming, welding and machining.
Export seaworthy packing.
