Mellanox MSB7800-ES2F InfiniBand EDR 100Gb/S Switch System 36 QSFP28 Ports

Product Description
Mellanox MSB7800-ES2F InfiniBand EDR 100Gb/s Switch System 36 QSFP28 Ports
1U Mellanox Network Switch
MSB7800-ES2F Mellanox Network switch Product Description
MSB7800-ES2F Networking provides the world’s first smart switch, enabling
in-network computing through the Co-Design Scalable Hierarchical Aggregation
and Reduction Protocol (SHARP) technology. SB7800 has the highest fabric
performance available in the market with up to 7.2Tb/s of non-blocking
bandwidth with 90ns port-to-port latency.

MSB7800-ES2F Built with NVIDIA Networking's latest Switch-IB 2 InfiniBand
switch device, EDR uses efficient 64/66 encoding while increasing the per
lane signaling rate to 25Gb/s. MSB7800-ES2F provides up to thirty-six
100Gb/s full bi-directional bandwidth per port. These stand-alone switches
are an ideal choice for top-of-rack leaf connectivity or for building small
to extremely large sized clusters.

MSB7800-ES2F enables efficient computing with features such as static
routing, adaptive routing, congestion control and enhanced VL mapping to
enable modern topologies (SlimFly, Dragonfly+, Torus). These ensure the
maximum effective fabric bandwidth by eliminating congestion hot spots. The
MSB7800-ES2F switch has best-in-class design to support low power
consumption. ATIS weighted power consumption is 136W for a fully-populated
switch. Power is further reduced if not all ports are used or if partially
utilized.



MSB7800-ES2F Benefits

Industry-leading switch platform in performance, power, and density

Designed for energy and cost savings

Collective communication acceleration

Quick and easy setup and management

Maximizes performance by removing fabric congestions

Backward compatible to FDR technology

MSB7800-ES2F Features

MSB7800-ES2F Performance

36 x EDR 100Gb/s ports in a 1U switch

7.2Tb/s aggregate switch throughput

90ns switch latency

122W typical power consumption

MSB7800-ES2F Optimized design

1+1 redundant & hot-swappable power

N+1 redundant & hot-swappable fans

80 gold+ and energy star certified power supplies

MSB7800-ES2F Advanced design

Adaptive routing

Congestion control

VL2VL mapping

Collective offloads (SHARP technology)

MSB7800-ES2F Mellanox Network card Parameter form
item

Features

Model

M , SB7800-ES2F

Height

2U

Width

430mm

Depth

390mm

Weigh , t

18kg

PerformancePerformance100Gb/s per port

100Gb/s per port
Connectors and cabling

36 x QSFP28

Products Status Stock
Ports 36
Transmission Rate 100Gb/s
Brand Name Mellanox
Performance 100Gb/s per port
Switch Radix 36 100Gb/s non-blocking
ports with aggregate data
throughput up to 7.2Tb/s
