TGJS-101 Inline Type Fiber Optic Splice Closure

As a fiber optic products supplier in the industry, TUOLIMA focuses on brand
customization, multi-selective product logo printing, high-end and independent
packaging design, to provide customers with a one-stop service that is quite
trusted by professionals worldwide.

TGJS-101 is one of the main equipment for user access points, applied for
protective connection and distribution between two or more cables.

The primary function of horizontal fiber optic splice enclosure is to connect
distribution cable and indoor cable in the open air. This inline fiber optic
splice closure is widely used in communication systems, cable TV, optical cable
network systems and others by virtue of steady structure, good sealing
performance and easy construction.

As a professional fiber optic cable manufacturing company, TUOLIMA can
customize the horizontal fiber optic splice closure according to your
requirements.

Details of TGJS-101 Inline Type Fiber Optic Splice Closure
The body is made of high quality engineering plastic with good strength;
3.2 With good waterproof design, the fiber optical splice closure can be
applied into underground and aerial.
3.3 Be equipped with 4 splice trays (each capacity is 12 cores) ; The maximum
can be 96 core (8 PCS 12F black trays).
3.4 Excellent fiber routing design ensures the radius curvature of the fiber
well and enough fiber storage space.

Specification of TGJS-101 Inline Type Fiber Optic Splice Closure
Model No. TGJS-101 Color Black
Capacity 48/96 cores Protection Level IP68
Material PP+GF Inlet/outlet 2/2
Dimension(MM) 480*155*110 Weight（KG） 2.3
