VMC-1165 3-AXIS MACHINING CENTER

The VMC-1165 3-Axis Machining Center is engineered for high-precision and
heavy-duty machining tasks. With its robust construction and advanced features,
it is ideal for industries requiring reliable performance and versatility.
3-Axis Machining Center Specifications
Item unit VMC-1165
Worktable area mm 1200*650
Worktable maximum loading kg 750
T-Slot(slot*width*distance) mm 5-18*120
Spindle nose taper BT BT40
XX/Y/Z axis travel mm 1100/650/650
Distance between spindle end face and worktable end face mm 100-750
Specifications of X, Y and Z axle guideways mm 45 (X-axis six sliders)
/45/45 (Z-axis six sliders)
Spindle  Speed (Belt type/Direct Connection) rpm 10000/12000
Tool magazine capacity T 24
X/Y/Z axis fast displacement m/min 36*36*36
Cutting feed speed m/min 1-8000
Repeated positioning accuracy mm 土0.003
Machine weight Kg 7000
VMC-1165 3-AXIS MACHINING CENTER
