Galvanized Steel Grating

Galvanized steel grating can be divided into hot-dip galvanized steel grating
and cold-dip galvanized (electro-galvanized) steel grating according to
different processes. Hot-dip galvanized steel grating is a more commonly used
type because of its long service life and excellent performance. Although the
cost of cold-dip galvanized (electro-galvanized) steel grating is lower than
that of hot-dip galvanizing, it has poor anti-corrosion performance and high
long-term maintenance and use costs.
Galvanized steel grating is a grid-like building material made of low-carbon
steel bearing bars and twisted square steel welded horizontally and vertically.
Its surface is galvanized to form a dense zinc-iron alloy layer, which enhances
corrosion resistance and service life.

1. Material : ASTM A36, A1011, A569, Q235, S275JR, stainless steel 304, low
carbon steel ,
etc.                      ,

   ,    ,
2. Bearing bar thickness: usually 2 mm - 12 mm , common thicknesses are 2 mm, 3
mm, 4 mm, 5 mm, 6 mm, 8 mm and 10 mm, etc. Steel gratings of different
thicknesses are suitable for different occasions, such as 2 mm thickness is
suitable for sidewalks, stair treads and other places, while 10 mm thickness is
suitable for factory workshops, docks and other places that need to bear heavy
loads.
3. Bearing bar width: 20mm - 100mm as required .
4. Bearing bar spacing: generally 30mm-100mm, common apertures are 30mm, 40mm,
50mm, 60mm, 70mm, 80mm, 90mm and 100mm, etc. Steel gratings with different
apertures are suitable for different drainage and load-bearing requirements.
5. Crossbar spacing: Crossbars are usually made of smaller round steel ,
twisted square steel or bearing bar . The diameter of the round steel is
generally 6-10mm, such as 6mm and 8mm round steel crossbars. The spacing of the
crossbars is mostly between 50-300mm, such as 100mm, 150mm, etc.
6. Zinc layer thickness : There are many options for the zinc layer thickness
of galvanized steel grating , ranging from 40g/m² to 610 g/m². The thickness of
the zinc layer is an important indicator to measure its anti-corrosion
performance. The thicker the zinc layer, the stronger the corrosion resistance
of the steel grating, and it is suitable for more severe environments.
7. Bearing bar type: I type, flat type, toothed type
8. Size : Customized according to customer needs

Let’s talk about your project. Contact us directly for fast support.
Customized Service
We understand that every project is unique, so we offer a comprehensive custom
service to our customers . Our experienced engineers and designers will work
closely with you to ensure the product meets your exact specifications.
1. Size and Shape: We can produce steel grating in any size and shape you
require.
2. Load Capacity: Customize load capacity to match your specific application.
3. Surface Treatment: Choose from hot-dip galvanizing, painting or other
special surface treatments.
4. Special Designs: We can create custom designs for complex applications or
unique project requirements.

Need detailed specs or certifications? Check our technical support and
download page.

Product Features

Strong corrosion resistance

The surface of galvanized steel grating is treated with hot-dip galvanizing to
effectively prevent oxidation and corrosion, and is particularly suitable for
use in humid and chemically corrosive environments.

High strength

Steel grating is made of high-quality low-carbon steel, has extremely high
strength and load-bearing capacity, and can withstand heavy loads for a long
time.

Good ventilation and lighting

The hollow design ensures good ventilation, lighting and drainage, reduces
water accumulation, and improves anti-slip performance.

Beautiful and durable

The galvanized surface is smooth and bright, not easy to accumulate dust and
easy to clean, while extending the service life of the product.

Easy installation

Steel grating can be cut into various specifications according to actual needs,
which is easy to install and reduces construction time and cost.

Low maintenance cost

The corrosion resistance of galvanized steel grating makes it unnecessary to
maintain frequently during long-term use, which reduces maintenance costs and
improves overall economic benefits.

Application and Scenarios

Uses

Galvanized steel grating is widely used in industrial platforms, stair treads,
gutter covers, petrochemical plants , sewage treatment plants, municipal
engineering and other fields . It is also used to make various special-purpose
products such as soundproof walls, ventilation ducts, cable trays, etc.


Scenario

Galvanized steel grating has a wide range of application scenarios, from
industrial buildings to civil buildings, from urban infrastructure to outdoor
landscape design, from land to marine engineering.
